Rota 4

Non Refrigerated General Purpose Centrifuge

Rota 4

Multi-talented for every day lab use.

Contact an Expert

Swing-out rotor

  • 700 ml
  • 4,500 rpm
  • 3,441xg

Fixed-angle rotor

  • 400 ml
  • 17,500 rpm
  • 24,652xg

User

  • Hospitals
  • Children's hospitals
  • Veterinary clinics
  • Food labs
  • Universities & Colleges
  • Pharmaceutical labs
  • Cell culture labs
  • Diagnostics

Non Refrigerated General Purpose Centrifuge

The general-purpose centrifuge Rota 4 is a versatile and indispensable centrifuge for virtually every task in everyday lab work. This all-purpose ventilated centrifuge is versatile in use and fits every lab thanks to its compact design and extensive range of rotors and accessories. This ensure that the Rota 4 can carry out virtually any centrifugation task. This machine can hold PCR tubes, test tubes, microtiter plates. The Rota 4 provides extraordinary capacity with 4x175ml in a swing-out rotor or 6x50ml in a fixed angle rotor. The Rota 4 also sets high standards in terms of safety. Automatic rotor detection, digital imbalance monitoring and service life monitoring of rotors and buckets ensure reliable operation.

lock

Ergonomic Lid Locking

Our precision lid-locking mechanism ensures a secure seal with minimal physical effort, reducing laboratory fatigue and enhancing user confidence during every operation.

aspect_ratio

Footprint

At just 39.5 cm wide, the Rota 4 maximizes your bench space while delivering professional‑grade rotational velocity.

volume_off

Whisper-Quiet Operation

Powered by a precision‑engineered European brushless motor, the Rota 4 delivers professional‑grade rotational velocity with minimal noise. This advanced motor design eliminates friction and vibration, ensuring smooth operation that reduces laboratory fatigue and maintains a calm working environment.

PDF
User Manual
PDF
Product Datasheet
PDF
Certificate
Max. capacity [ml]
Swing-out rotor(max capacity [ml]) 700 [ml] 4x175ml
Fixed-angle rotor(max capacity [ml]) 400 [ml] 4x100ml
Max. RCF 24,652 x g
Max. speed [rpm] 17500
Min. speed [rpm] 800
Noise level at maximum speed (approximate) [db(A)]
Fixed-angle rotor (8241L) 56 db (A)
Swing-out rotor with bucket(404175) 50 db (A)
Max. acceleration time [s]
Fixed-angle rotor (84100) 36
Swing-out rotor with bucket (404175) 35
Max. braking time [s]
Fixed-angle rotor (84100) 27
Swing-out rotor with bucket (404175) 21
Temperature setting range [°C Ambient
Power consumption [W] 500
Height x Width x Depth [mm] 400 x 395 x 527
Height with open lid [mm] 810
Weight without rotor [kg] 50
Fixed-angle rotor 12082
Fixed-Angle Rotor 200151

L006x50ml

6 x 50 ml
10,000 rpm
10,509 x g
Fixed-angle rotor 12097
Fixed-Angle Rotor 200206

A004x100ml

4 x 100 ml
5,000 rpm
2,823 x g
Fixed-Angle Rotor 200226

L012x15ml

12 x 15
10,000 rpm
11,404 x g
Fixed-Angle Rotor 200253

A012x005ml

12 x 5 ml
14,000 rpm
22,351 x g
Fixed-Angle Rotor 200148

A048x1.5ml

48 x 1.5 ml
10,000 rpm
10,062 x g
Fixed-Angle Rotor 200380

A030x1.5ml

30 x 1.5 ml
15,000 rpm
25,155 x g
Swing-Out Rotor 200202

S384x0.5ml

384 x 0.5 ml
4,000 rpm
2,075 x g
Swing-Out Rotor 200155

S192x0.5ml

192 x 0.5 ml
2,000 rpm
581 x g
Fixed-Angle Rotor 200673

A010x008ml

10 x 8 ml
14,000 rpm
17,092 x g rcf
Fixed-Angle Rotor 200676

A020x005ml

20 x 5 ml
14,000 rpm
15,339 x g
Fixed-Angle Rotor 200674

A024x1.5ml

24 x 1.5 ml
17,500 rpm
24,652 x g
Fixed-Angle Rotor 200675

L024x1.5ml

24 x 1.5 ml
15,000 rpm
21,382 x g
Fixed-Angle Rotor 200680

A032x0.2ml (PCR)

32 x 0.2 ml
15,000 rpm
15,345 x g
Fixed-Angle Rotor 200679

A004x030 ml

4 x 30 ml
14,000 rpm
16,215 x g
Fixed-Angle Rotor 200678

A006x30ml

6 x 30 ml
10,000 rpm
9,168 x g
Swing-Out Rotor 200681

S010x1.5ml

10 x 1.5 ml
8,000 rpm
6,010 x g
